KSACC101Q Quartz Accelerometer ±70g 400Hz Digital Output

  • 1
  • 2

Brand Name : KACISE

Model Number : KSACC101Q

Certification : CE

Place of Origin : CHINA

MOQ : 1PCS

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability : 1000 Piece/Pieces per Week negotiable

Delivery Time : 5-8work days

Packaging Details : each unit has individual box and all boxes are packed in standard packages or customers requests available

Input Voltage : 15±1 VDC

Power consumption : ≤75mW @15VDC

Range : ±70g

Scale factor : 56Hz/g±5Hz/g

Scale factor repeatability(1σ,one month) : ≤50ppm

Bandwidth : ≥400Hz

Contact Now

KSACC101Q Quartz Accelerometer ±70g 400Hz Digital Output
Product Attributes
Attribute Value
Input Voltage 15±1 VDC
Power consumption ≤75mW @15VDC
Range ±70g
Scale factor 56Hz/g±5Hz/g
Scale factor repeatability(1σ,one month) ≤50ppm
Bandwidth ≥400Hz
Product Description

The KSACC101Q quartz vibration beam accelerometer is a solid-state digital output acceleration sensor featuring large range, compact size, high precision, low power consumption, fast start-up time, shock vibration resistance, and exceptional reliability. These characteristics make it superior to traditional analog output accelerometers.

Key Features
  • Digital output
  • Wide Bandwidth
  • Low Power Consumption
  • High Reliability
  • Wide Operating Temperature Range
  • Compact Size
  • Fast Start-Up
Applications
  • Spaceflight
  • Aviation
  • Navigation
  • weapon systems
  • Vehicle systems
KSACC101Q Quartz Accelerometer ±70g 400Hz Digital Output
Technical Specifications
Power Supply Parameters
Power Voltage 14~16VDC
Power @25°C 75mW @15VDC
Supply current 5mA
Product Performance
Range ±70g
Size 22mm×22mm×14mm
Bias 0g±2g
Bias stability ≤100ug
Bias temperature sensitivity 100ug/°C
Bias repeatability ≤100ug
Scale factor 56Hz/g±5Hz/g
Scale factor temperature sensitivity 500ppm/°C
Second order nonlinear coefficient ≤80μg/g²
Second order nonlinearity coefficient repeatability ≤50μg/g²
Scale factor repeatability ≤50ppm
Temperature sensor 40KHz±2%(0.3Hz/°C)@25°C
Noise <10μg
Threshold ≤1×10⁻⁵g
Bandwidth ≥400Hz
Weight ≤23g
Environmental Specifications
Operating temperature -45°C～+85°C
Storage temperature -55°C～100°C
Random vibration 5grms (20Hz～2000Hz)
Sine vibration 10g peak,50 to 800Hz
Working shock 100g
Shock 200g
